DSU-D Dual-Stage Filter

Home Products Dialysis Filtration Dialysis Water For Central Water Systems DSU-D Dual-Stage Filter
OverviewBenefitsSpecsDocumentationRelated

Overview

  • Market: Healthcare – Dialysis
  • Application: RO/DI Machines
  • Solution: Bacteria / Viruses / Endotoxins
  • Product Number: 70-0235D

The Nephros DSU-D filter is intended to be used to filter water or bicarbonate concentrate used in hemodialysis devices. It assists in providing hemodialysis quality water or bicarbonate concentrate. The device is not a complete water treatment system, but serves to remove biological contaminants. Therefore it must be used in conjunction with other water treatment equipment (Reverse Osmosis (RO), Deionization (DI), etc.).

Contact us for additional information
Nephros DSU-D

Benefits

  • Proprietary 5 nanometer (0.005 micron) membrane technology for bacteria, virus, and endotoxin retention

  • FDA-cleared filter which meets and exceeds, ISO 23500-5:2019 standard for dialysis water or bicarbonate concentrate

  • >11-log bacteria reduction (B.diminuta); >8-log virus reduction; >5-log endotoxin reduction

  • Designed to meet stringent requirements as final filter for centralized water and bicarbonate for HD machines

  • Long continuous 12-month filter life reduces frequency of filter changes

  • Available with quick-connect or 1/2″ threaded connections

Specs

  • Compatible Disinfection: Chemical and Heat
  • Max Differential Pressure: 75psi (5 bar)
  • Filter Membrane: Medisulfone®
  • Membrane Material: Polysulfone
  • Pore Size: 5nm (0.005micron)
  • Bacteria Retention: >1011 (B. diminuta)
  • Virus Retention: >108 (PhiX-174)
  • Endotoxin Retention: >105 EU/ml
  • Dimensions: 13” L x 2.5”D
  • Connections Recommended: Quick Connect (CPC (APC))
  • Replacement: 1 year
  • Safety: Dual-Stage Filtration
  • ~60kDa Particle Retention >104 (Hgb)

Associated Installation Kits & Components

  • 70-0294 Install Kit – Dialysis In-Line Filters

Product Documentation

Brochure
Installation Guide
Instructions
